Desktop Scanners

Category Details Core Performance Imaging Technology: CMOS global exposure Light Source: 617 nm red LED Image Size: 640 × 480 (optional 800 × 600) Scan Angle: ±60° (L/R), ±54° (F/B), 360° rotation Scan Rate: 120 fps Field of View: 48° (H) × 30° (V) Printing Contrast: ≥20% Minimum Resolution: 4 mil Decoding Capability 1D Codes: EAN-13, EAN-8, UPC-A, UPC-E0, UPC-E1, Code128, Code39, Code93, Interleaved 2 of 5, Industrial 25, Matrix 2 of 5, Code11, CodeBar, MSI, RSS-14, RSS-Ltd, RSS-Exp, Standard 2 of 5, Plessey, China Post

Category Details Core Performance Imaging Technology: CMOS global exposure Light Source: 617 nm red LED Image Size: 640 × 480 (optional 800 × 600) Scan Angle: ±60° (L/R), ±54° (F/B), 360° rotation Scan Rate: 120 fps Field of View: 48° (H) × 30° (V) Printing Contrast: ≥20% minimum Minimum Resolution: 4 mil Decoding Capability 1D: EAN-13, EAN-8, UPC-A, UPC-E0, UPC-E1, Code128, Code39, Code93, Interleaved 2 of 5, Industrial 25, Matrix 2 of 5, Code11, CodeBar, MSI, RSS-14, RSS-Ltd, RSS-Exp, Standard 2 of 5, Plessey, China Post 25, GS1 Composite 2D: QR Code, Data Matrix (DM), PDF417, Han Xin, Micro PDF417, Micro QR Code, MaxiCode, Aztec Code, Code16K Special: Supports mobile screen barcode reading Operating Modes Scan Mode: Auto-sensing / Continuous scanning Setup Method: Press button + scan setup codes Prompt Modes: Buzzer + LED indicator Connectivity Communication Interfaces: USB-HID keyboard, USB-COM virtual serial port, RS232 serial port Interface Type: USB Type-B Physical Specifications Housing Material: ABS + PC Cable: 1.35m straight line cable Dimensions: 148 × 97 × 97 mm (Product), 170 × 115 × 115 mm (Packaging) Weight: Net 326 g; Gross 336 g Power & Environment Input Voltage: DC 5V ±10% Current: Working – 240 mAh; Standby – 190 mAh Operating Temperature: 0°C ~ 50°C Storage Temperature: -20°C ~ +70°C Operating Humidity: 5% – 95% (non-condensing)

Category Details Performance Scanning Modes: Key trigger / Automatic sensing / Continuous scanning Sensor: 300,000-pixel global CMOS Light Source: Self-luminous LED Resolution: 640 × 480 Scan Rate: 120 fps Scan Angle: 60° (H) × 60° (V), 360° rotation Connectivity Communication Interfaces: USB-HID keyboard, USB-COM virtual serial port Interface Type: USB User Interaction Prompt Methods: Buzzer, LED indicator, vibration motor Setup Method: Manual sequential scanning of setup codes Durability Waterproof/Dustproof Rating: IP54 (protection against dust and water splashes)

X7-1000A Two-dimensional Barcode Scanning Platform Sensor CMOS global exposure Light Source 617nm red LED Image Size 640 × 480 (optional 800 × 600) Scan Angle ±60°, ±54°, 360° (left, right, front, back, rotation) Scan Rate 120 fps Field of View 48° (H) × 30° (V) Printing Contrast Minimum 20% Minimum Resolution ≥ 4 mil Decoding Ability 1D: EAN-13, EAN-8, UPC-A, UPC-E, Code128, Code39, Code93, Interleaved 2 of 5, Industrial 25, Matrix 2 of 5, Code11, Codabar, MSI, RSS-14, RSS-Ltd, RSS-Exp, Standard 2 of 5, Plessey, China Post 25, GS1 Composite2D: QR Code, Data Matrix (DM), PDF417, Han Xin, Micro PDF417, Micro QR Code, MaxiCode, Aztec Code, Code16KSupports mobile screen code reading Scan Mode Auto-sensing / Continuous scanning Communication Interface USB-HID keyboard, USB-COM (virtual serial), RS232 Interface Type USB TYPE-B Prompt Mode Buzzer, LED light Setup Method Press the key and manually scan setting codes Housing Material ABS + PC Cable Straight line 1.35m Dimensions 148 × 97 × 97 mm (scanner); 170 × 115 × 115 mm (packaging) Weight 326g (net); 336g (gross) Input Voltage DC 5V ±10% Current Working: 240 mA; Standby: 190 mA Temperature 0°C ~ 50°C (working); -20°C ~ +70°C (storage) Humidity 5% ~ 95% (non-condensing)

Category Details Key Features 300,000-pixel global exposure scan engine Larger scanning window & adjustable angle Easy setup with function buttons 4 sound styles + LED indicators Multi-system compatibility Warranty: 1 year Performance Scan Mode: Auto-sensing / Continuous Scan Type: CMOS global exposure Resolution: 640 × 480 Light Source: 617 nm red LED Scan Rate: 120 scans/sec Scan Angle: ±60° / ±54° / 360° rotation Field of View: 48° (H) × 30° (V) Contrast: ≥20% Min. Resolution: 4 mil Decoding Capability 1D Codes: EAN-13, EAN-8, UPC-A, UPC-E, Code128, Code39, Code93, ITF, Industrial 2 of 5, Matrix 2 of 5, MSI, RSS, GS1, etc. 2D Codes: QR, Data Matrix, PDF417, Micro QR, Aztec, MaxiCode, Code16K, Han Xin, etc. Special: Mobile screen barcode reading Connectivity Interfaces: USB-HID, USB-COM, RS232 Port Type: USB Type-B Setup: Button + scan codes Prompt Modes: Buzzer + LED Physical Material: ABS + PC Cable: 1.3m straight line Product Size: 158 × 92 × 94 mm Box Size: 170 × 115 × 115 mm Weight: 335g (net), 345g (gross) Power & Environment Voltage: DC 5V ±10% Current: 240mAh (working), 190mAh (standby) Temp: 0°C ~ 50°C (working), -20°C ~ +70°C (storage) Humidity: 5% – 95% non-condensing
