U8 Wired 2D Barcode Scanner – Fast & Reliable
Key Features
| U8 2D Wired Barcode Scanner (50W) - Specifications | |
|---|---|
| Sensor | Global Exposure CMOS |
| Resolution | 640 × 480 pixels |
| Trigger Modes | Manual, Auto-sensing, Continuous |
| System Interfaces | USB keyboard, USB virtual COM, RS-232 serial |
| Transfer Mode | USB cable (data + charging) |
| Prompt Modes | Buzzer + LED indicators |
| Read Accuracy | QR codes ≥5MIL; 1D codes ≥3MIL |
| Symbol Contrast | ≥15% |
| Power Consumption | 1.60W (working), 0.40W (standby) |
| Current | 320mA (operating); 80mA (standby); 5V ±10% @ 350mA |
| Dimensions | 165 × 67 × 97 mm |
| Weight | 180g (without cable) |
| Cable | 1.6m straight line, one-piece design |
| Material | PC+ABS durable housing |
| Operating Temperature | 0°C – 50°C |
| Storage Temperature | -40°C – 60°C |
| Humidity | 5% – 95% (non-condensing) |
